Stainless Steel Link Chain

We provide all kinds of marine anchor chain, with CCS, LR, ABS, BV, IRS and other classification societies certificates. Our chains are divided into stud link anchor chain, studless anchor chain, stainless steel anchor chain and stainless steel link chain, ect.

Send Inquiry

Product Description

German Din764 stainless steel Link Chain

SIZE		INSIDE LENGTH			INSIDE WIDTH	OUTSIDE SIFTH	11 LENGTH PER 11 LINKS			KG/100m WEIGHT PER 100M	BREAKING LOAD	PROOF LOAD
MM	±MM	MM	±MM		MM	MM	MM	±MM		KG	KN	KG
4	0.2	16	0.3	0.2	5	14	176	1.6	0.9	31.3	7	400
5	0.2	18	0.4	0.2	7	18.2	198	1.8	1	51.4	11.8	680
6	0.2	21	0.5	0.2	8	21.5	231	2	1.1	74	16.5	850
8	0.2	28	0.5	0.3	11	29	308	2.2	1.2	131.5	32	1680
10	0.3	35	0.6	0.3	14	36	385	2.7	1.5	200	50	2630
12	0.3	42	0.6	0.3	16	41	462	3.2	1.8	298	70	3680
13	0.4	45	0.7	0.4	18	47	495	3.5	2.0	350	80	4200
14	0.45	49	0.75	0.45	20	48	539	3.8	2.0	406	92	4830
16	0.5	56	0.9	0.5	22	58	616	4.3	2.5	520	125	6700
18	0.8	63	1	0.5	24	65	693	4.7	2.8	650	160	8400
20	1	70	1.1	0.6	27	72	770	5.4	3.2	820	200	10000
23	1.2	80	1.3	0.7	31	83	880	6.2	3.5	1100	250	13000
26	1.3	91	1.5	0.8	35	94	1001	7.0	4.0	1400	320	16000

German Din766 stainless steel Link Chain

SIZE		INSIDE LENGTH			INSIDE WIDTH	OUTSIDE SIFTH	11 LENGTH PER 11 LINKS			WEIGHT PER M
MM	±MM	MM	±MM		MM	MM	MM	±MM		KG
2	0.2	12	0.2	0.2	3.5	7.5	132	1	0.5	0.07
3	0.2	16	0.2	0.2	4.2	11	176	1.4	0.7	0.16
4	0.2	16	0.3	0.2	5	13.7	176	2.1	1.1	0.32
5	0.2	18.5	0.4	0.2	6	17	203.5	2.4	1.2	0.5
6	0.2	18.5	0.4	0.2	7.2	20.2	203.5	2.4	1.2	0.8
7	0.3	22	0.4	0.2	8.4	23.8	242	3.0	1.4	1.1
8	0.3	24	0.4	0.2	9.6	27.2	264	3.2	1.5	1.4
9	4	27	0.5	0.3	10.8	30.6	297	3.6	1.8	1.8
10	0.4	28	0.5	0.3	12	34	308	3.7	1.9	2.2
11	0.4	31	0.5	0.3	13.2	37.4	341	4.0	2.0	2.7
12	0.3	36	0.6	0.3	14.4	40.8	396	4.4	2.2	3.1
13	0.5	36	0.6	0.3	15.6	44.2	396	4.6	2.4	3.8
14	0.6	41	0.7	0.4	16.8	47.56	451	5.4	2.7	4.4
16	0.6	45	0.8	0.4	19.2	54.4	495	6.0	3.0	5.7
18	0.9	50	0.8	0.4	21.6	61.2	550	6.6	3.3	7.3
19	0.4	53	0.9	0.4	22.8	64.6	583	7.0	3.7	7.97
20	1.0	56	1.0	0.5	24	68	616	7.4	3.7	9
22	1.2	62	1.1	0.5	26.4	75	682	8.0	4.0	11
23	1.2	64	1.1	0.5	27.6	78.2	704	8.4	4.2	12
26	1.3	73	1.2	0.6	31.2	88.4	803	9.6	4.8	15
28	1.4	78	1.3	0.65	33.8	95.2	858	10.2	5.1	18
30	1.5	84	1.4	0.7	41	102	924	11	5.5	19.5
32	1.6	90	1.5	0.75	43	108.8	990	11.8	5.9	23
